The HD3201URL Portable Network Decoder features a 1/2U compact design. It supports AVS+/H.265/H.264/MPEG2 decoding and IP input, with multiple resolutions including 1080P/1080I/720P/576I/480I.
It supports audio formats such as DRA/AC3/EAC3/AAC/MPEG. It also supports network streaming via RTMP for live streaming on platforms like Douyin, Taobao, and WeChat. Product Features IP input supported Rich interfaces: CVBS/HDMI/SD/HD-SDI/AES/EBU Supports AVS+/H.265/H.264/MPEG2 decoding Supports HTTP/HTTPS/HLS/M3U8/RTSP/RTMP/MMS/Bluray Supports Biss_1/Biss_E descrambling Supports DRA/AC3/EAC3/AAC/MPEG audio formats Compatible with HD and SD signals Resolution can be auto-detected or manually set Browser-based B/S Web management
Technical Specifications TS over IP | Interface | 1×RJ-45, 10/100 Base-T | Effective Bitrate | 90Mb/s (100 Base-T) | Protocols | UDP/RTP/HTTP/HTTPS/HLS/M3U8/RTSP/RTMP/MMS/Bluray | HDMI Output | Standard | 1×HDMI interface | Resolution & Frame Rate | 1080P60/1080P50/1080i60/1080i50/720p60/720p50/576P/576I/480P/480I | Video Decoding | Standards | MPEG-2/MPEG-4/H.264 AVC/H.265(HEVC)/AVS+ | Audio Decoding | Standards | MPEG-1 Layer I/II, MPEG-2 Layer II, MPEG-2 AAC, MPEG-4 AAC LC 2-CH/5.1 CH AC3/DRA/EAC3 | HD/SD-SDI Output | Interface | 2×BNC, 75Ω | SD-SDI | SMPTE 259M, 270 Mb/s (10bit) | HD-SDI | SMPTE 292M, 1.485 Gbit/s (20bit) | Analog Audio Output | Interface | 2×BNC | Audio Mode | Left, Right, Dual Mono, Stereo | Digital Audio Output | Interface | 1×AES/EBU | Analog Video Output | CVBS Interface | 1×BNC, 75Ω | CVBS Standards | PAL BDGHI, PAL N, NTSC M, PAL N-C, NTSC M, NTSC M443, PAL M, SECAM, NTSC MJ | Data Output | Subtitle | DVB/EBU | Teletext | DVB/EBU | Closed Caption | EIA 608, EIA 708, EIA 608-to-708 | Local & Remote Management | Interface | 1×RJ-45, 10/100 Base-T Management Port | Remote Control | HTTP Web | Physical Specifications | Dimensions | 220×240×44mm | Weight | Net 1KG | Power | AC 90V～250V, 50/60Hz | Power Consumption | 24W |
|
