2x1 RF Switch L-Band RF Changeover Switch

1. RF Frequency Range (Operating Bandwidth): Optional 5–1000MHz / 950–2150MHz

2. 2-input 1-output RF switch, 2x1 switching function.

Product Introduction:

Model: LNB/RF SW 2*1
This device is used for primary/backup channel switching of L-Band RF signals. It provides dual RF signal level detection and dual optical level detection. When the primary channel has no RF signal, no optical signal, or its level falls below the preset switching threshold due to failure, the detection circuit automatically switches to the backup channel via MCU control. It will automatically switch back to the primary channel once the fault is resolved. The unit is equipped with an auto/manual switch for manual channel switching if required. Fault indicators are provided on the panel; LEDs automatically activate when signal levels drop below preset values.

2. Specifications:
Frequency Range: 950~2150 MHz
Insertion Loss:<4dB
Frequency Response: 2dB±1dB
Isolation: >40dB
Switch Threshold: <-45dBm
Power Supply: DC13–20V
Operating Temperature: -20~+65℃
3. Panel Description
Front Panel:
OP: Channel A Optical Fault Alarm LED
RF: Channel A RF Fault Alarm LED
OP: Channel B Optical Fault Alarm LED
RF: Channel B RF Fault Alarm LED
CHA: Channel A Active LED
Manual A/B Channel Switch
CHB: Channel B Active LED
Auto: Auto Mode LED
Auto/Manual Control Switch
Manual: Manual Mode LED
Rear Panel:
Channel B Input
Channel A Input
RF Output
DB9 Connector: Power input, CHA & CHB alarm level input

● Frequency Range: 950~2150 MHz

● Insertion Loss:<4dB

● Frequency Response: 2dB±1dB

● Isolation: >60dB

● Switch Threshold: -20dBm ~ -50dBm

● Power: 100~240V AC, 50Hz, 20W
